JINPAT Fieldbus Slip Rings provide dependable rotating connectivity for industrial communication systems. Supporting both fieldbus protocols (Profibus-DP, DeviceNet, CANbus, Modbus, InterBus) and industrial Ethernet (EtherCAT, Profinet, Ethernet/IP), they deliver high-speed, interference-free data transfer. The modular construction allows seamless integration into diverse machinery and automation setups.

Product Details

Key Features

Broad Protocol Compatibility: Handles Profibus, CANbus, CC-Link, EtherCAT, Profinet, Modbus TCP, and more.

Optimized Signal Integrity: Dedicated channel design reduces noise and prevents data loss.

Robust & Compact: Engineered for space-limited and high-demand environments.

Flexible Customization: Adaptable channel types and combinations to match different bus protocols.


Applications

Servo motor and controller communications in automation systems

Imaging and scanning platforms

Renewable energy systems (wind turbine control)

Battery manufacturing machinery

High-end laser processing equipment

Customization
Custom-built slip rings with tailored circuits, protective enclosures, and protocol-specific configurations are available upon request.


Profibus Slip Rings

Typical Model

Circuits

Voltage

Size(mm)

 Profibus channels

Other signal channel

Compatible with both signal types

Inner Diameter

Outer diameter Length Special signals Normal signals  Special signals (U2, U3, SDI, E2, E3、HD-SDI)
Standard signals (CAN/CANbus, Profibus, RS422/485, CC-Link, DeviceNet, etc.)

LPC-24-02E2-01E3

24 0~380AC/DC 0 Φ22
49.8
1
3

/

Fast Ethernet、Gigabit Ethernet
/

LPC-56A-02S-04E3

56 0~380AC/DC 0 Φ25 85.7 2 / Gigabit Ethernet /

LPT038-0406-08S

4 220VAC/24VAC Φ38.1 Φ105 124 / 5 / /

LPT120-0510-2403-02S

5*10A/24*3A
0~380AC/DC Φ120 Φ212 211.5 1 / / / /

CAN/RS422/485 Slip Rings

Typical Model Circuits Voltage

Size(mm)

 Profibus channels Other signal channel Compatible with both signal types
Inner Diameter Outer diameter Length Special signals Normal signals  Special signals (U2, U3, SDI, E2, E3、HD-SDI) Standard signals (CAN/CANbus, Profibus, RS422/485, CC-Link, DeviceNet, etc.)

LPC-18-0306-0602-01S

18
0~380AC/DC
0 Φ22 42.3 / / / /

LPC-24-0406-0801-03S-IP54

24 48VAC/DC 0 Φ22 49 1 / / / /

LPC-24YT-0208-0201-01E3-04S

24 0~48V AC/DC 0 Φ24.8 54.8 1 1 / Gigabit Ethernet /

LPC-30-0316-03S-IP65

30 0~380AC/DC 0 Φ22 57.3 3 /
/ / /

LPC-D32-0210-26S-04SD1-01E3

32 0~24V AC/DC
0 Φ32 109 5 5 / Gigabit Ethernet、HD-SDI RS232
LPC-36-08S-05E2-IP51 36 48V AC/DC 0 Φ25 64 2 5 / Fast Ethernet /

LPC-36-0104-0211-0202-02S-01E2

36 24V/48V AC/DC
0 Φ22 57.3 2 1
/ Fast Ethernet
/

LPC-56-0104-0215-0203-02S-01E2

56 48V AC/DC 0 Φ25 85.7 1 1 / Fast Ethernet /

LPC-56-54S

56 0~28V AC/DC 0 Φ25 85.7 2 / 38 / RS232/ Differential

LPC-56-23S-02E3-01SDI-IP51

56 0~380AC/DC 0 Φ25 85.7 23 2 / Gigabit EthernetSDI /

LPC-56-0415-02S-01E2-01E3-IP54

56 0~24V AC/DC 0 Φ105 103 2 2 / Fast Ethernet、Gigabit Ethernet /

LPT012-0208-0202-06S

2*8A

2*2A

0~28V AC/DC Φ 12.7mm Φ56 64.4 1 / 1 / Encoder signal

LPT050-6305-04S-16GND

60 220VAC/24DC Φ 50mm Φ160 339.2 4 / / / /

LPT000-0436-0410-40S-01A

4*36A

4*10A

48VDC 0 Φ119 113.6 40 / / / /

CC-Link Slip Rings

Typical Model Circuits Voltage

Size(mm)

Profibus channels Other signal channel Compatible with both signal types
Inner Diameter Outer diameter Length Special signals Normal signals  Special signals (U2, U3, SDI, E2, E3、HD-SDI) Standard signals (CAN/CANbus, Profibus, RS422/485, CC-Link, DeviceNet, etc.)

LPC-D30-1501-01S

30 /
0 Φ30 / 1 / / / /

LPC-D39-20S-05E3

39 0~24VAC/DC 0 Φ39 140.5 4 5 0 Gigabit Ethernet /

TMC-LPC-76A

0 0~240VAC 0 Φ35.5 105.7 2 3 / Fast Ethernet、Gigabit Ethernet /

LPT400-0730-04S

7*30A 0~400VAC Φ 400 Φ660 321 1 / / / /

DeviceNet Slip Rings

Typical Model Circuits Voltage

Size(mm)

Profibus channels Other signal channel Compatible with both signal types
Inner Diameter Outer diameter Length Special signals Normal signals  Special signals (U2, U3, SDI, E2, E3、HD-SDI) Standard signals (CAN/CANbus, Profibus, RS422/485, CC-Link, DeviceNet, etc.)

LPT080-0220-05S-01A

2*20A
Φ 80 5 / / 240VAC/220AC Φ170 171.6 / /
