Features
High-Speed Performance: Supports data transfer up to 480 Mbps (USB 2.0) and 5 Gbps (USB 3.0) with minimal signal loss.
Multi-Signal Integration: Combine USB with Ethernet, HDMI, SDI, power, and control signals in one assembly.
Compact & Reliable Design: Ideal for systems requiring stable operation in limited spaces.
Custom Options: Fully customizable circuits, connectors, and mechanical configurations to fit your specific needs.
Why Choose JINPAT?
We don’t just provide a slip ring — we deliver a reliable, long-lasting solution.
Known for exceptional quality and backed by 24/7 technical support, we ensure your projects succeed without compromise.
Contact Us Today
Need a USB Slip Ring tailored to your project? Our team is ready to respond quickly to your request.
Send us your inquiry now and receive a customized quotation within 24 hours.
USB3.0 Slip Rings | |||||
Typical Model |
USB 3.0 Channels | Circuits | Voltage | Size | |
| Outer Diameter | Length | ||||
LPMS-01U3 |
1 | / | 0~48V AV/DC | ∅7.6 | 19.1 |
LPMS-01U3-0301 |
1 | 3 | ∅7.98 | 22 | |
LPM-01U3 |
1 | / | 0~110V AV/DC | ∅12.8 | 23.5 |
LPM-01U3-1001-05S |
1 | 10 | ∅16 | 37 | |
LPC-01U3-0502-10S |
1 | 5 | 0~220V AV/DC | ∅22 | 57.3 |
LPC-02U3-0602 |
2 | 6 | ∅25 | 85.7 | |
USB2.0 Slip Rings | |||||
| Typical Model | USB 3.0 Channels | Circuits | Voltage | Size | |
| Outer Diameter | Length | ||||
LPMS-01U2-0601-04S |
1 | 6 | 0~48V AV/DC | ∅7.6 | 19.1 |
LPMS-02U2-0201-06S |
2 | 2 | ∅7.98 | 22 | |
LPM-02U2-0402-04S |
2 | 4 | 0~110V AV/DC | ∅12.8 | 23.5 |
LPM-04U2-0501-05S |
4 | 5 | ∅16 | 37 | |
LPC-02U2-1002-16S |
2 | 10 | 0~220V AV/DC | ∅22 | 57.3 |
LPC-08U2-1002-06S |
8 | 10 | ∅25 | 85.7 | |
