VR Slip Ring
Head-mounted VR displays use wires to connect directly to computers, televisions, or other multimedia devices. During use, issues such as rotation and twisting inevitably limit the angle of rotation and reduce the experience.
LPC-0104-0402-HD01-U2
Head-mounted VR displays use wires to connect directly to computers, televisions, or other multimedia devices. During use, issues such as rotation and twisting inevitably limit the angle of rotation and reduce the experience.
In order to ensure that data transmission is simultaneously completed under uninterrupted 360° high-speed rotation, ensuring data integrity and transmission speed, Jingpei has designed a variety of VR slip rings that integrate HDMI, USB and DC power supply, and amplified signals. The VR slip ring's HD video transmission capacity can reach an error-free signal of 2160X1080P@90HZ.
The HD signal and USB signal do not interfere with each other to ensure lossless signal transmission. This solution allows users to rotate 360 degrees without restriction when using the head-mounted VR display, greatly improving the user experience. Typical product models include LPC-0104-0402-HD01-U2 and LPT000-0204-0202-03S-HD01-02U2, which have been successfully used in HTC Viva helmets, virtual gaming chairs, game consoles, etc.
| Electrical & Electronics | Mechanical | Enviromental | |||
| Number of Circuits |
2 circuits*1.5A/1 circuit*DC/ 2 circuits*4A1 circuit*HDMI/ 1 circuit*USB2.0 |
Rotating Speed |
0~100 rpm | Temperature | -20℃~+60℃ |
| Current | 4A |
Contact Material |
Gold-to-gold | Humidity | ≤60%RH |
| Voltage | 48V |
Housing Material |
Engineering plastic | Protection Grade | IP40 |
|
Dielectric Strength |
≥200V@50Hz | Wire Type |
AWG22#/AWG26# AWG28#/ AWG30#/USB2.0 /HDMI/DC |
Others | |
|
Insulation Resistance |
≥50MΩ@200V | Life Span | / | ||
| Electrical Noise | ≤15mΩ(Signal Ring) | Wire Length |
Rotor: 250±5mm Stator: 250±5mm |
||
