Ethernet slip ring-LPT025-0202-0202-E3-U2
High transmission speed of up to 1000 Mbps. Able to integrate multiple signal channels.
LPT025-0202-E3-U2（JP13-041-04）:
Industrial Ethernet is an Ethernet technology applied in the industrial field. This technology is compatible with commercial Ethernet, the IEEE 802.3 standard. However, the slip ring products related to the two domains are quite different. When designing industrial slip rings for Ethernet, many things are taken into consideration to meet industrial requirements: Materials, product applicability, timeliness, interoperability, reliability, anti-interference performance, intrinsic safety, etc.
The Industrial Ethernet slip ring is a slip ring specially designed for industrial Ethernet transport. JINPAT's Industrial Ethernet slip ring supports various protocols such as Sercos III, Powerlink, ProfiNet, EtherCAT, Ethernet/IP, Modbus/TCP, etc. It is the ideal solution for transferring industrial Ethernet between system components.
Advantages of JINPAT Industrial Ethernet slip ring:
High transmission speed of up to 1000 Mbps.
Able to integrate multiple signal channels. Maximum channel capacity: 8 Gigabit Ethernet channels and 12 100M Ethernet channels.
Hybrid transmission of power and other complex signals.
Various slip ring models. Optional Gigabit Ethernet slip rings with internal diameter from 0 to 120 mm. Optional 100 metre Ethernet slip rings with internal diameter from 0 to 200 mm.
Superb connection materials ensure low electrical noise and extremely long service life.
Various connector types to choose from.
| Electronic & Electruc | Mechanical | |||
| Circuits | Total | 16 CKT | Working Speed | 0~300rpm |
| Detail | 2X2A / 1Group 1000Mbps Ethernet 1Group USB2.0 |
Inner Diameter | φ25.4mm | |
| Rating Voltage | 24VAC/DC | Contact Material | Precious Metal | |
| Dielectric Strength | ≥500VAC@50Hz(P) /300VAC@50Hz(S) |
Housing Material | Aluminum Alloy | |
| Insulation Resistance | ≥500MΩ@500VDC(P) ≥100MΩ@300VDC(S) | Lead Wire Length |
Stator: 1000mm Rotor: 1000mm |
|
| Environment | Remarks | |||
| Working Temperature | -20°C~+60° | Application | / | |
| Working Humidity | ≤60%RH | Other | / | |
| IP | IP50 | Note:"P" stands dor power, "S" stands for signal | ||
