Dual-axis analog turntable slip rings are advanced rotary connectors designed to provide seamless transmission of power, signals, and data between stationary and rotating parts in turntable systems that require both horizontal and vertical rotation. These slip rings are ideal for applications in 2D motion platforms, testing equipment, and simulation systems, where precise control and uninterrupted performance are crucial. Engineered to handle the unique demands of dual-axis movement, they ensure smooth operation across both axes with minimal friction and wear. Built with high-quality materials for durability, these slip rings are designed for long-term reliability and low maintenance, offering exceptional performance in demanding environments. Whether for entertainment, training, or industrial use, dual-axis analog turntable slip rings enhance the efficiency and functionality of rotational systems.
| Electrical & Electronics | Mechanical | Enviromental | |||
|
Number of channels |
88CKT | Working speed |
0~100rpm | Operating temperature |
-20°C~+50°C |
| Working current | 10x21A+5x14A+12x5A+15x2A+4xA+20xSignal+2XE2+PE |
Contact material |
Precious metal/ Gold to Gold |
Working humidity |
≤60%RH |
| Operating voltage | 700/300/400VAC |
Shell material |
Aluminium alloy | Class of protection | IP44 |
| Compressive strength |
≥1000VAC@50Hz ≥300VAC@50Hz |
Conductor length |
/ | Others | |
| Insulation resistance |
500MΩ@500VDC 100MΩ@300VDC |
Dynamic resistance fluctuation value |
/ | Life span | Can be customized |
| Electrical noise |
≤10mΩ(at 50rmp) | ||||
For more information about this slip ring product, feel free to reach out to JINPAT.
We are committed to providing you with a tailored solution that meets your needs!
