100T All-Ground Crane Slip Rings
Rotary slip rings for 100T all-terrain cranes are engineered to provide reliable and seamless transmission of power, signals, and data between the stationary and rotating parts of heavy-duty mobile cranes
Rotary slip rings for 100T all-terrain cranes are engineered to provide reliable and seamless transmission of power, signals, and data between the stationary and rotating parts of heavy-duty mobile cranes. Designed for 100-ton capacity all-terrain cranes, these slip rings ensure smooth and uninterrupted operation across diverse terrains, from construction sites to challenging environments. Built with high-strength materials to endure heavy loads, vibrations, and extreme weather conditions, they offer long-lasting performance and minimal maintenance. Customizable to meet specific operational needs, rotary slip rings for 100T all-terrain cranes enhance crane efficiency, safety, and reliability, making them essential components for maximizing crane performance in demanding applications.
LPT200-0430-0210-06S - 100T All terrain crane
| Electrical & Electronics | Mechanical | Enviromental | ||||
| Loop number | total | 14 | Working speed |
0~100rpm | Operating temperature |
-30°C~+80°C |
| Details |
4*30A+2*10A+3*5A +4 CAN bus +1* throttle signal |
Contact material |
Precious metals |
Working humidity |
≤95%RH | |
| Operating voltage | 360VDC |
Shell material |
Aluminium alloy | Class of protection | IP67 | |
| Compressive strength | ≥500VAC@50Hz |
Conductor length |
Stator 3500mm Rotor :1500m |
Others | ||
| Insulation resistance | ≥500MΩ@500VDC |
Dynamic resistance fluctuation value |
/ | Life span | Can be customized | |
For more information about this slip ring product, feel free to reach out to JINPAT.
We are committed to providing you with a tailored solution that meets your needs!
