LPPL06 Standard Pneumatic Rotary Unions
The LPP rotary unions can perform rotation of 360 degrees. The medium includes inert gas such as compressed air
The LPP rotary unions can perform rotation of 360 degrees. The medium includes inert gas such as compressed air, steam, vacuum, nitrogen, hydrogen, etc. It can integrate slip ring to transport various control signals. The sealing surface and sealing ring are made of special materials, with the advantages of wear resistance, long life, corrosion resistance, and no leakage. Customers can install LPP rotary unions independently according to the application environment.
| LPPL06 Standard Pneumatic Rotary Unions | |||||||||
| Model Code | Circuits | Medium | Bore Diameter | Maximum Working Pressure |
Working Speed | Connector type | Size |
Torque | Lead Time |
| LPPL06-02A | 2 | Compressed Air | 6 | -0.15 Kpa1Mpa | 0～100rpm | M5 | φ6*φ40*47 | ≤0.6N·m | 2-3 |
| LPPL06-04A | 4 |
Compressed Air | 6 | -0.15 Kpa1Mpa | 0～100rpm | M5 | φ6*φ40*63 | ≤0.8N·m | 2-3 |
| LPPL06-06A | 6 | Compressed Air | 6 | -0.15 Kpa1Mpa | 0～100rpm | M5 | φ6*φ40*79 | ≤1.0N·m | 2-3 |
| LPPL06-08A | 8 | Compressed Air | 6 | -0.15 Kpa1Mpa | 0～100rpm | M5 | φ6*φ40*95 | ≤1.3N·m |
2-3 |
| LPPL06-10A | 10 | Compressed Air | 6 | -0.15 Kpa1Mpa | 0～100rpm | M5 | φ6*φ50*122 | ≤1.6N·m | 2-3 |
| LPPL06-12A | 12 | Compressed Air | 6 | -0.15 Kpa1Mpa | 0～100rpm | M5 | φ6*φ50*141 | ≤2.0N·m | 2-3 |
