The LPFO fiber optic slip ring, also known as a fiber optic rotary joint or fiber optic rotary connector, uses optical fibers as the data transmission medium, providing an optimal solution for transmitting ultra-large volumes of data and signals between system components with rotational connections.
The transmission rate can exceed 100 Gbit/s, with up to 50 channels in a highly integrated, compact, and lightweight design. It comes in various packaging forms and features extremely low insertion loss and very high return loss. Multi-channel options include single-mode, multi-mode, or a combination of both. It also boasts excellent waterproof and dustproof capabilities and is suitable for a wide range of temperatures. For additional requirements, please contact us so that our sales engineers can recommend a suitable slip ring model or design a custom slip ring for you!
Specifications | |||
Fiber types |
SM(9/125um) MM(50/125um or 62.6/125um) |
Jacket types | 2.0mm/armor |
| Channel number | 3 | Connector types | FC/SC/ST/LC(PC or APC) |
Wavelength range |
SM:1310/1550nm MM:850/1300nm |
Estimated life cycle |
＞100 million revolutions |
Insertion loss |
＜4dB | Vibration | MIL-STD-167-1A |
| Insertion loss ripple | ＜2dB | Mechanical shock | MIL-STD-810G |
Return loss |
SM:≥40dB MM:≥25dB |
IP rating |
IP65 or IP67 |
Crosstalk |
≥50dB | Max Optical power | 23dBm |
Maximum speed |
300rpm | Package style | Pigtails on both ends |
Working temperature |
-20～+65℃ |
Weight, approx | 200g（No tail cable andconnection included） |
Storage temperature |
-45~+75℃ | Fiber tpes | / |
LPFO-03N-A Product Outline Diagram
