LPA000-0780 Large Volume Series Slip Rings
An integrated slip ring solutions that enable a safe and reliable 360-degree constantly rotary transmission of power, signals, gas and fluid.
LPA000-0780-0740-0915PE-0705PE-08S-FO12 Slip Ring features high working voltage, withstand high sealing pressure and anti-explosion. An integrated slip ring solutions that enable a safe and reliable 360-degree constantly rotary transmission of power, signals, gas and fluid.
Significance:
1. To enhance the technology standard of slip ring for mining equipment.
2. This slip ring has gone through high sealing pressure test. Provides precious experience for enhancing wire sealing.
3. Provide practical and powerful slip ring solutions for the electric oil drilling system.
Technical Breakthrough:
1. Enable a reliable 360-degree rotary high voltage transmission in a compact structure.
2. Rid of sealing problems caused by wire leads going through drill rod.
3. Anti-explosion features.
This is a marine crane slip ring. Power capacity and channel number are optional.
Can integrate with signal module, pneumatic/hydraulic module and multi-channel fiber optic rotary joints.
Optional protection grading and explosion-proof grading.
Electronic & Electric |
Mechanical |
|||
| Circuits | Total | 44CKT |
Working Speed |
0~300RPM |
| Detail | 9x100A+4x55A+9x25A+5x15A+4xsignal+12xFO |
A hole diameter |
/ |
|
Rating Voltage |
3200VAC/240VAC/24VAC | Contact Material | Engineering Plastic |
|
Dielectric Strength |
7000VAC@50Hz(P) |
Housing |
Stainless Steel 316 |
|
Insulation Resistance |
≥1000MΩ@1000VDC(P) ≥100MΩ300VDC(S) |
Installation |
Fixed part: (not specified) |
|
Environment |
Remarks |
|||
Working Temperature |
-18°C~+45°C |
Application |
Marine Crane |
|
Working Humidity |
≥100%RH |
|||
IP |
IP56 |
Other |
/ | |
For more customized solutions, please feel free to contact us at any time!
