LPA130-031000 Large Volume Series Slip Rings
This is JINPAT’s latest slip ring for podded propeller.
This is JINPAT’s latest slip ring for podded propeller. This custom slip ring allows integrated transmission of power, signals, liquid and gas.
With case design and special housing, the slip ring demonstrates fine resistance against salt spray, oil mist and corrosion, etc. Therefore,
JINPAT podded propeller slip ring is able to provide reliable and stable service to the podded propeller under complex applied environment.
Electronic & Electric |
Mechanical |
|||
| Circuits | Total | 54CKT |
Working Speed |
0~2RPM |
| Detail | 5*1000A+1*PE+50*signal |
A hole diameter |
/ |
|
Rating Voltage |
690VAC/220VAC/24VDC | Contact Material | High Quality Graphite / Precious Metal |
|
Dielectric Strength |
2500VAC@50Hz(P) |
Housing |
Spray coating Q235 (color will be determined) |
|
Insulation Resistance |
≥500MΩ@1000VDC(P) ≥10MΩ250VDC(S) |
Installation |
Vertical installation |
|
Environment |
Remarks |
|||
Working Temperature |
-20°C~+45°C |
Application |
propeller ship |
|
Working Humidity |
≥95%RH |
|||
IP |
IP65 |
Other |
/ | |
For more customized solutions, please feel free to contact us at any time!
