LPA000-02600 Large Volume Series Slip Rings
JINPAThas many years expertise in supplying standard and customized construction products for harsh environments and is a leading manufacturer of high performance.
JINPAThas many years expertise in supplying standard and customized construction products for harsh environments and is a leading manufacturer of high performance.
* Cranes and Excavators
* Electrified Zero Emission Mobile Machinery
* Autonomous Vehicles
* Construction Robotics
* Haptics for Construction and Mining Robotic Arm
At JINPAT we believe that electrification, connectivity , and automation are interconnected themes that build upon each other.This idea has driven the design of JINPAT’s mobile machinery platform; built for a zero emission, increased productivity, and an always connected future. We collaborate with you to customize our platform to the unique needs of your machine— It’s how JINPAT helps get you to your future, faster.
Electronic & Electric |
Mechanical |
|||
| Circuits | Total | 18CKT |
Working Speed |
0~10rpm |
| Detail | 2x600A+4x40A+9xsignal+2xCANbussignal |
A hole diameter |
/ |
|
Rating Voltage |
450V~750VDC/24V~32VDC | Contact Material |
High-end Copper Garbon Brush /Precious Metal |
|
Dielectric Strength |
power ring: ≥2500VAC@50Hz signal ring: ≥500V@50Hz |
Shell Material |
Q235 Spray coating(yellow) |
|
Insulation Resistance |
power ring: 500MΩ1000VDC |
Lead Wire Length |
/ | |
Environment |
Remarks |
|||
Working Temperature |
-30°C~+80°C |
Application |
Construction Machinery |
|
Working Humidity |
≤95%RH |
|||
IP |
IP67 |
Other |
/ | |
