LPT038 Series Through Bore Slip Rings
The LPT038 provides an economical and readily available solution when a compact through-bore configuration is required.
The LPT038 provides an economical and readily available solution when a compact through-bore configuration is required.
This unit offers a 38.1mm bore for routing hydraulic or pneumatic lines and a compact 86mm outside diameter for minimal space applications. 15 amps per circuit are available in 6, 12, 18 and 24 ring configurations in 4 housing lengths.
Electronic & Electric |
Mechanical | |||
Circuits |
Total |
6 CKT |
Working Speed |
0~300rpm |
Detail |
6A |
Inner Diameter |
∅38.1mm |
|
Rating Voltage |
380VAC/DC |
Contact Material |
Precious Metal |
|
Dielectric Strength |
1000VAC@50Hz |
Shell Material |
Aluminum alloy |
|
Insulation Resistance |
≥500MΩ@500VDC |
Lead Wire Length |
Stator:300mm Rotor:300mm |
|
Environment |
Remarks | |||
Working Temperature |
-20°C~+60°C |
Application |
/ |
|
Working Humidity |
≤60%RH |
Other |
/ |
|
IP |
IP54 or higher |
Note: "P" stands for power, "S" stands for signal. |
||
